Turn Glass Surfaces into Powerful Digital Advertising Spaces
The 10.4 Transparent LED Display from Omchan India Pvt. Ltd. is designed to deliver impactful visual communication while preserving the openness and transparency of modern architectural spaces.
Transparent LED Display for Retail, Commercial, and Architectural Applications
The 10.4 Transparent LED Display from Omchan India Pvt. Ltd. is designed to deliver impactful visual communication while preserving the openness and transparency of modern architectural spaces. With transparency above 80%, high brightness performance, and lightweight construction, this display solution is ideal for storefronts, glass facades, airports, shopping malls, and commercial buildings.
Key Product Highlights:
- Transparency Above 80%
- Brightness Above 6500 cd/sqm
- Lightweight Construction
- Wide Viewing Angle
Advanced Transparent LED Display Solution
The 10.4 Transparent LED Display is designed for organisations seeking an effective balance between digital communication, advertising impact, and architectural aesthetics. Unlike conventional LED displays, transparent LED technology enables vibrant digital content to be displayed while preserving visibility through glass surfaces, making it an ideal solution for modern commercial environments.
Featuring transparency levels above 80%, the display offers one of the highest see-through experiences available within the transparent LED display category. Businesses can transform existing glass facades, storefronts, and windows into dynamic communication platforms without affecting natural light flow or the architectural appearance of the building.
The display delivers brightness exceeding 6500 cd/sqm, ensuring excellent content visibility even in high ambient light environments. Its wide 160° viewing angle allows audiences to experience clear and consistent visuals from multiple directions, helping maximise audience engagement and advertising effectiveness.
With a refresh rate above 3840Hz, the display supports smooth video playback, seamless animations, and professional-quality content presentation. This makes it suitable for advertising campaigns, brand promotions, product launches, event communication, and digital information displays.
The lightweight construction simplifies installation and reduces structural load requirements, making the display suitable for both new architectural projects and retrofit applications. Its transparent design integrates naturally into contemporary buildings while enhancing their visual appeal.
Manufactured and supplied by Omchan India Pvt. Ltd., the 10.4 Transparent LED Display provides a reliable, energy-efficient, and visually impressive solution for retail storefronts, shopping malls, airports, hotels, exhibition centres, corporate buildings, and premium commercial installations.
KEY FEATURES OF 10.4 TRANSPARENT LED DISPLAY
Ultra-High Transparency
Transparency above 80% preserves visibility through glass surfaces while delivering impactful digital content.
High Brightness Output
Brightness exceeding 6500 cd/sqm ensures excellent content visibility in commercial and high-ambient-light environments.
Wide Viewing Angle
The 160° viewing angle enables clear content visibility across broad viewing positions and directions.
Lightweight Design
With a weight of approximately 13.5 kg/sqm, the display supports easier installation and architectural integration.
Smooth Content Playback
Refresh rates above 3840Hz provide seamless video playback, animations, and professional content presentation.
Modern Architectural Integration
Designed to complement contemporary commercial buildings, glass facades, storefronts, and architectural projects.
Energy-Efficient Operation
Optimised power consumption supports cost-effective long-term operation in commercial display environments.
Commercial-Grade Performance
Engineered for continuous operation in retail, hospitality, corporate, transportation, and advertising applications.
Benefits of 10.4 Transparent LED Display
Preserve Building Aesthetics
Maintains the architectural appearance of glass facades while enabling dynamic digital communication and advertising.
Maximises Natural Visibility
Ultra-high transparency allows occupants, visitors, and customers to see through the display without obstruction.
Enhances Brand Presence
Creates visually engaging advertising, promotional campaigns, and branding opportunities that attract attention.
Utilises Existing Glass Infrastructure
Transforms storefront windows, facades, and glass surfaces into valuable digital communication assets.
Supports Modern Architectural Projects
Integrates naturally into contemporary commercial buildings, retail spaces, airports, and premium developments.
Lightweight Installation
Lower display weight simplifies installation planning and reduces structural load requirements.
Professional Visual Communication
Supports branding, advertising, information display, customer engagement, and promotional objectives.
Long-Term Commercial Value
Provides an innovative platform for digital engagement, brand visibility, customer attraction, and revenue generation.
10.4 Transparent LED Display – Technical Specifications
The 10.4 Transparent LED Display is engineered to provide ultra-high transparency, excellent brightness, and seamless integration into modern architectural environments. It is an ideal solution for retail storefronts, commercial buildings, shopping malls, airports, hotels, exhibition centres, and premium glass facade applications where both visibility and digital communication are important.
| Specification | Details |
|---|---|
| Pixel Pitch | 10.4 × 10.4 mm |
| LED Type | SMD1921 |
| Module Size | 500 × 125 mm |
| Module Resolution | 48 × 16 Dots |
| Brightness | > 6500 cd/sqm |
| Viewing Angle | 160° |
| Pixel Density | 4,608 Dots/sqm |
| Frame Change Frequency | 50–60 Hz |
| Scanning Mode | 1/2 Scan |
| Refresh Rate | > 3840 Hz |
| Maximum Power Consumption | ≤ 720 W/sqm |
| Transparency | > 80% |
| Gray Scale | 16 Bit |
| Protection Grade | IP4X |
| Heat Dissipation | 65 W |
| Weight | 13.5 Kg/sqm |
| Working Temperature | 20°C – 45°C |
| Working Voltage | 180–220V (±10%) |
Applications of 10.4 Transparent LED Display
The 10.4 Transparent LED Display is designed for a wide range of professional environments requiring exceptional visual quality, reliability, and seamless performance.
Corporate Boardrooms
Control Rooms
Broadcast Studios
Digital Signage Networks
Experience Centers
Conference Halls
Education Facilities
Retail Showrooms
Industries Using 10.4 Transparent LED Display
The 10.4 Transparent LED Display is used across multiple industries where high-resolution visuals, reliability, and professional presentation are essential.
Corporate & Enterprise
Government & Public Sector
Media & Broadcasting
Retail & Commercial
Education
Healthcare
Hospitality
Transportation
Why Choose Omchan India
Omchan India Pvt. Ltd. is a trusted manufacturer and supplier of advanced LED display and digital signage solutions, serving businesses, institutions, architects, retailers, and organisations across diverse industry sectors. Our focus on innovation, quality, and customer satisfaction helps clients implement effective visual communication systems that enhance engagement and brand visibility.
With years of industry expertise and a strong commitment to delivering reliable display technologies, we provide solutions tailored to meet the evolving requirements of commercial, retail, hospitality, transportation, education, healthcare, and public-sector environments.
Industry Experience:
Trusted supplier of LED video walls, transparent LED displays, digital signage systems, kiosks, and integrated display solutions.
Certified Quality:
Products are manufactured according to recognised quality standards and tested to ensure dependable performance and reliability.
Installation & Maintenance Guidelines for 10.4 Transparent LED Display
The 10.4 Transparent LED Display is designed for installation in retail storefronts, commercial buildings, shopping malls, airports, hotels, exhibition centres, and architectural glass facade applications. Proper installation planning should include evaluation of mounting structures, display dimensions, power requirements, content objectives, and site-specific environmental conditions.
Transparent LED displays require careful consideration of glass surface compatibility, structural support systems, cable routing, and controller placement. Proper planning helps maintain architectural aesthetics while ensuring stable display operation and long-term reliability.
Particular attention should be given to display positioning and viewing angles to maximise content visibility and audience engagement. Correct placement ensures that the transparent display enhances communication without obstructing natural visibility through glass surfaces.
Installation should be carried out by experienced professionals according to project requirements and site conditions. Proper integration of display modules, power systems, receiving cards, and signal infrastructure contributes to efficient and dependable operation.
Effective power management, signal distribution, and content management systems are essential for maintaining smooth content playback and consistent visual performance. Adequate ventilation and protection from environmental factors further support system longevity.
Routine maintenance should include inspection of display modules, controllers, power supplies, signal transmission systems, mounting components, and electrical connections. Preventive maintenance helps identify potential issues before they affect performance.
Regular cleaning of transparent LED panels is recommended to maintain transparency levels, maximise brightness output, and ensure optimal content visibility. Approved cleaning methods should be used to protect display components and preserve image quality.
Working with Omchan India’s technical team helps ensure efficient installation, reliable operation, professional commissioning, and long-term maintenance support. Expert guidance can significantly improve system performance and maximise return on investment.
Frequently Asked Questions
1. What is a 10.4 Transparent LED Display?
2. Where is a 10.4 Transparent LED Display commonly used?
3. What is the transparency level of the display?
4. What is the brightness level?
5. What is the viewing angle?
6. Is it suitable for glass installations?
7. What is the refresh rate?
8. Is it suitable for advertising applications?
9. Does Omchan India provide installation support?
10. What is the key advantage of a 10.4 Transparent LED Display?
